MQL Micro Lubrication System Unit - 1.5L
SKU: 8501024V
Introducing the Excision Micro Quantity Lubrication (MQL) System, a state-of-the-art solution for precise and efficient lubrication consumption. This system allows users to apply the exact quantity of lubrication required for the process, with the option to set lubrication times as either interval or constant. The system is easy to mount to existing systems and does not produce any leftover mist or smoke, making it a clean and safe option for use in any setting.
This MQL system is designed for use in areas that require frequent adjustment changes, such as circular saw machines, threading machines, milling machines, routers, band saws, and lathes. It features a user-friendly interface with knobs for easy time settings and can also be installed to be compatible with PLC control units upon request. By adding a pump, up to 5 points can be operated simultaneously.
The system boasts a range of advanced technical specifications such as working voltage of 24V AC/DC, a working pressure of 4-6 Bar, and a viscosity range of 2-30 cst. It also includes standard features such as a low-level switch, oil filling filter, and the ability to output to up to 5 pumps (max). This system can be used with a variety of liquids such as herbal essential cutting oils, industrial oils, solvent-based essential oils, and chain and gear oils.
Overall, the Excision Micro Quantity Lubrication System is a highly advanced and efficient solution for precise lubrication consumption, increasing tool life and production time, and reducing the need for filter systems.
- Easy mount to the systems.
- The leftover, mist or smoke does not occur.
- Can be used internally or externally.
- Increases the Tool life.
- Increases the production time.
- Does not need any filter system.
- Different nozzle types can apply.
MQL 1.5L
It is designed for use in areas that require frequent adjustment changes. The time setting is made extremely simple thanks to the knobs. It can also be installed as compatible with plc control units upon request. By adding a pump, up to 5 points can be operated simultaneously.
TECHNICIAL SPECIFICATIONS
- Working Voltage: 24V AC / DC
- Working Pressure: 4 - 6 Bar
- Oil Amount Min: 0,0012 ml
- Oil Amount Max: 0,028 ml
- Lubrication Interval: 0.1sec – 10 sec
- Lubrication Time: 0.1sec – 10 sec
- Reservoir: 1,5 litre
- Viscosity Range: 2-30 cst
STANDARD FEATURES;
- Low level switch
- With oil filling filter
- Up to 5 pumps output feature (Max.)
- For each output nozzle is required
SCOPE OF APPLICATION;
- Circular saw machines
- Threading machines
- Milling machines
- Scrubbing benches
- Routers
- Band saws
- Swich drills
- Lathes
LIQUIDS THAT CAN BE USED;
- Herbal essential cutting oils
- Industrial oils
- Solvent based essential oils
- Chain and gear oils
